ISO Adaptor For Mercedes C Class W203 W204 CLK W209 GL Wiring Harness

This adaptor will enable you to replace your factory fitted head unit with an aftermarket model.

It converts the cars power and speaker plug into a standard ISO connection, suitable for all aftermarket head units (Alpine, Clarion, JVC, Kenwood, Pioneer, Sony etc).

You simply plug one end of the adaptor into your cars original wiring harness, and the other end into the new head unit.

(With vehicles that have the new Fakra or Quadlock connection there is no ignition switched 12v supply. This is usually required for aftermarket head units, and they won't power up with out this being connected)

 Fits vehicle models including:

Mercedes-Benz A-Class [W169 & W176] (2004-2016)

Mercedes-Benz B-Class [W245 & W246] (2005-2016)

Mercedes-Benz C-Class [W203 & W204] (2004-2014)

Mercedes-Benz CLK [W209] (2004-Onwards)

Mercedes-Benz GL [X164] (2006-2016)

Mercedes-Benz ML {W164 & W166] (2005-2016)

Mercedes-Benz R Class [W251] (2006-Onwards)

Mercedes-Benz Sprinter [W639] (2006-2016)

Mercedes-Benz Vito [W639] (2006-2014)

Vauxhall Astra (2004-2010)

Vauxhall Corsa (2004-2014)

Vauxhall Meriva (2005-2010)

Vauxhall Vectra (2004-2008)

Vauxhall Zafira (2005-2014)

Vauxhall Agila (2004-2007)

Vauxhall Movano (2006-2013)

Vauxhall Vivaro (2006-2012)

Vauxhall Antara (2006-2010)

Vauxhall Combo (2001-2011)

Vauxhall GTC (2004-2009)

The above list of vehicles is a general guide and cannot be guaranteed in all cases.

*PLEASE NOTE*

Installation Note:

 Connect loose red cable to an 12v ignition driven live.

Orange cable requires connection to illumination wire but only if the new radio requires this.

 Blue wire needs to be connected to the Remote Antenna or ignition supply wire (if rem ant wire not available) on back of new car stereo.

To ensure compatibility, we recommend that the vehicle connector pictured above is compared to the actual connector on your vehicle
