Pakkauksen leveys

36 mm

Pakkauksen syvyys

109 mm

Pakkauksen korkeus

126 mm

Pakkauksen paino

133 g

Vaatimustenmukaisuustodistukset

CE, RoHS, REACH

Pluggable on auxiliary contact block

Ei

Semiconductor output

Ei

Function star-delta

Ei

Function delay-on energization

Kyllä

Ajastimen kesto (min)

0,05 s

Ajastimen kesto (maks.)

100 s

Actuating voltage type

AC/DC

Electrical connection type

Screw connection

Rated control supply voltage (DC)

12 - 240 V

Rated control supply voltage (AC 50Hz)

12 - 240 V

Rated control supply voltage (AC 60Hz)

12 - 240 V

Number of outputs (delayed, change-over contact)

1

Function floating contact on energization

Ei

Function delay on de-energization

Ei

Function floating contact on de-energization

Ei

Function pulse shaping

Ei

Remote operation possible

Ei

Suitable as remote control

Ei

Function flashing (starting with pause, fixed time)

Ei

Function flashing (starting with pulse, fixed time)

Ei

Clock function (starting with pause, variable)

Ei

Clock function (starting with pulse, variable)

Ei

Outputs (reversible delayed/undelayed)

Ei
