Main circuit connection type

Frame clamp

Number of auxiliary NC contacts

2

Number of auxiliary NO contacts

2

Actuating voltage type

AC/DC

Rated operational power (AC-3, 400V)

55 kW

Suitable for distribution boards

Kyllä

Operating voltage AC (50Hz)

1000 V

Operating coltage AC (60Hz)

1000 V

Number of NO main contacts

3

Rated operation current (Ie at AC-3, 400V)

115 A

Rated operation current (Ie at AC-1, 400V)

160 A

Rated operation power (NEMA)

100 hp

Rated operation current (Ie at AC-4, 400V)

97 A

Rated control supply voltage (DC)

500 - 550 V

Rated control supply voltage (AC 50Hz)

500 - 550 V

Rated control supply voltage (AC 60Hz)

500 - 550 V

Rated operational power (AC-4, 400V)

55 kW

Tuotteen korkeus

172 mm

Pakkauksen leveys

190 mm

Pakkauksen syvyys

129 mm

Pakkauksen korkeus

181 mm

Pakkauksen paino

3,64 kg

Minimi tilausmäärä

1 kpl
