Main circuit connection type

Spring clamp connection

Actuating voltage type

AC

Overload release current setting

0.28 - 0.4 A

Degree of protection (NEMA)

Other

AS-i protocol support

Ei

INTERBUS protocol support

Ei

SERCOS protocol support

Ei

SUCOnet protocol support

Ei

SafetyBUS p protocol support

Ei

DeviceNet Safety protocol support

Ei

INTERBUS Safety protocol support

Ei

DATA-HIGHWAY protocol support

Ei

LON protocol support

Ei

DeviceNet protocol support

Ei

AS-i Safety at Work protocol support

Ei

PROFINET CBA protocol support

Ei

CAN protocol support

Ei

FOUNDATION Fieldbus protocol support

Ei

PROFIsafe protocol support

Ei

PROFIBUS protocol support

Ei

PROFINET IO protocol support

Ei

TCP/IP protocol support

Ei

Modbus-protokolla

Ei

EtherNet/IP protocol support

Ei

Release class

Luokka 10

Number of command positions

1

Suitable for emergency stop

Kyllä

Rated operational current (Ie)

0,4 A

Rated operational current (AC-3, 400V)

0,4 A

Temperature-compensated overload protection

Kyllä

Rated conditional short-circuit current (Type 1, 480Y/277V)

65 kA

Rated conditional short-circuit current (Type 2, 230V)

150 kA

Rated conditional short-circuit current (Type 2, 400V)

150 kA

Rated conditional short-circuit current (Type 1, 600Y/347 V)

30 kA

Suitable for rail mounting

Ei

External reset possible

Ei

Other bus system protocol support

Ei

Auxiliary/control circuit connection type

Spring clamp connection

Short-circuit release

Kyllä

Ympäröivä lämpötila (max)

60 °C

Coordination type according to IEC 60947-4-3

Luokan 2

Tuotteen korkeus

260 mm

Pakkauksen leveys

221 mm

Pakkauksen syvyys

306 mm

Pakkauksen korkeus

87 mm

Pakkauksen paino

1,05 kg

Minimi tilausmäärä

1 kpl
