Rated operation power (at AC-3, 230 V, 3-phase)

0,06 W

Main circuit connection type

Screw connection

Number of auxiliary NC contacts

1

Number of auxiliary NO contacts

1

Actuating voltage type

DC

Overload release current setting

0.5 A

Rated operational power (AC-3, 400V)

0,12 kW

AS-i protocol support

Ei

INTERBUS protocol support

Ei

SERCOS protocol support

Ei

SUCOnet protocol support

Ei

SafetyBUS p protocol support

Ei

DeviceNet Safety protocol support

Ei

INTERBUS Safety protocol support

Ei

DATA-HIGHWAY protocol support

Ei

LON protocol support

Ei

DeviceNet protocol support

Ei

AS-i Safety at Work protocol support

Ei

PROFINET CBA protocol support

Ei

CAN protocol support

Ei

FOUNDATION Fieldbus protocol support

Ei

PROFIsafe protocol support

Ei

PROFIBUS protocol support

Ei

PROFINET IO protocol support

Ei

TCP/IP protocol support

Ei

Modbus-protokolla

Ei

EtherNet/IP protocol support

Ei

Release class

Class 10A

Rated control supply voltage (DC)

24 V

Suitable for emergency stop

Ei

Number of indicator lights

4

Rated operational current (Ie)

0,5 A

Rated operational current (AC-3, 400V)

0,5 A

Temperature-compensated overload protection

Ei

Suitable for rail mounting

Kyllä

External reset possible

Kyllä

Other bus system protocol support

Ei

Auxiliary/control circuit connection type

Spring clamp connection

Short-circuit release

Ei

Ympäröivä lämpötila (max)

60 °C

Tuotteen korkeus

100 mm

Pakkauksen leveys

36 mm

Pakkauksen syvyys

109 mm

Pakkauksen korkeus

167 mm

Pakkauksen paino

287 g

Minimi tilausmäärä

1 kpl
