Main circuit connection type

Rail connection

Number of auxiliary NC contacts

2

Number of auxiliary NO contacts

2

Actuating voltage type

AC/DC

Suitable for distribution boards

Kyllä

Operating voltage AC (50Hz)

1000 V

Operating coltage AC (60Hz)

1000 V

Number of NO main contacts

3

Rated operation current (Ie at AC-3, 400V)

225 A

Rated operation current (Ie at AC-1, 400V)

275 A

Rated operation power (NEMA)

150 hp

Rated operation current (Ie at AC-4, 400V)

195 A

Rated control supply voltage (DC)

220 - 240 V

Rated control supply voltage (AC 50Hz)

220 - 240 V

Rated control supply voltage (AC 60Hz)

220 - 240 V

Rated operational power (AC-4, 400V)

110 kW

Tuotteen korkeus

210 mm

Pakkauksen leveys

265 mm

Pakkauksen syvyys

196 mm

Pakkauksen korkeus

234 mm

Pakkauksen paino

6,44 kg

Minimi tilausmäärä

1 kpl
