Main circuit connection type

Screw connection

Number of auxiliary NO contacts

1

Actuating voltage type

AC

Rated operational power (AC-3, 400V)

7,5 kW

Suitable for distribution boards

Kyllä

Operating voltage AC (50Hz)

690 V

Operating coltage AC (60Hz)

690 V

Number of NO main contacts

3

Rated operation current (Ie at AC-3, 400V)

16 A

Rated operation current (Ie at AC-1, 400V)

22 A

Rated operation power (NEMA)

10 hp

Rated operation current (Ie at AC-4, 400V)

11,5 A

Tuotteen korkeus

58 mm

Pakkauksen leveys

50 mm

Pakkauksen syvyys

61,5 mm

Pakkauksen korkeus

77,5 mm

Pakkauksen paino

230 g

Minimi tilausmäärä

1 kpl
