Main circuit connection type

Screw connection

Number of auxiliary NC contacts

2

Number of auxiliary NO contacts

2

Actuating voltage type

DC

Rated operational power (AC-3, 400V)

11 kW

Suitable for distribution boards

Kyllä

Operating voltage AC (50Hz)

690 V

Operating coltage AC (60Hz)

690 V

Number of NO main contacts

3

Rated operation current (Ie at AC-3, 400V)

25 A

Rated operation current (Ie at AC-1, 400V)

40 A

Rated operation power (NEMA)

15 hp

Rated operation current (Ie at AC-4, 400V)

15,5 A

Tuotteen korkeus

85 mm

Pakkauksen leveys

54 mm

Pakkauksen syvyys

92 mm

Pakkauksen korkeus

159 mm

Pakkauksen paino

648 g

Minimi tilausmäärä

1 kpl
