Main circuit connection type

Screw connection

Number of auxiliary NC contacts

1

Number of auxiliary NO contacts

1

Actuating voltage type

AC

Rated operational power (AC-3, 400V)

45 kW

Suitable for distribution boards

Kyllä

Operating voltage AC (50Hz)

690 V

Operating coltage AC (60Hz)

1000 V

Number of NO main contacts

3

Rated operation current (Ie at AC-3, 400V)

95 A

Rated operation current (Ie at AC-1, 400V)

130 A

Rated operation power (NEMA)

75 hp

Rated operation current (Ie at AC-4, 400V)

80 A

Tuotteen korkeus

140 mm

Pakkauksen leveys

164 mm

Pakkauksen syvyys

171 mm

Pakkauksen korkeus

83 mm

Pakkauksen paino

1,71 kg

Minimi tilausmäärä

1 kpl
